Assa Abloy 843ZY DROP BOLT LOCK KEY O/R 12/24V DC

Assa Abloy 843ZY DROP BOLT LOCK KEY O/R 12/24V DC

The Assa Abloy 843ZY Drop Bolt is designed with a compact structure and versatile accessories, allowing for flexible installation in various settings. Serving as an additional locking mechanism, it enhances security for both residential and commercial properties. This particular model features a Euro profile cylinder hole, enabling a mechanical emergency release function for added safety and convenience.

• For horizontal and vertical fitting
• When fitted horizontally, only possible to close downwards
• Can also be fitted to the surface of glass doors
• Automatic unlocking for 9 seconds via integrated control
• Integrated door and locking monitoring contacts
• Suitable for short and permanent release
• Suitable for swing doors

Technical Specifications:

• Rated operating voltage tolerance range: ± 10 %
• Input operating voltage: 12-24 V DC
• 12 V starting current: 1500 mA
• 24 V starting current: 1000 mA
• 12 V latching current: 130 mA
• 24 V latching current: 95 mA
• Housing length: 228 mm
• Housing width: 22 mm
• Housing depth: 38 mm
• Width face plate: 25 mm
• Face plate thickness: 3 mm
• Material face plate: Stainless steel
• Diameter dead bolt: 12.7 mm
• Bolt throw: 16 mm
• Distance between faceplate and striking plate: max. 6 mm
• Installation position: Vertical and horizontally (closed downwards only)
• Holding force: 10000 N
