SRS Fail-Safe/Fail-Secure Electric Lock for Double Swing Doors
£237.01
£197.51
SKU
ML210
- This product is available to order. The lead time is normally 2 – 4 working days.
- An accurate despatch date will be confirmed with you once order is received by our sales team (during office hours).
Free Delivery on this product
SRS ML210 Fail-Safe/Fail-Secure Electric Lock for Double Swing Doors. Suitable for horizontal or vertical installation with 12~24Vdc operating voltage
SRS ML210 Fail-Safe/Fail-Secure Electric Lock for Double Swing Doors
Fail-Safe/Fail-Secure Electric Lock for Double Swing Doors. Suitable for horizontal or vertical installation with 12~24Vdc operating voltage.
Features:
- Fail-Safe/Fail-Secure (Selectable)
- For double swing doors
- Horizontal or vertical installation
Technical Specifications:
- Operating voltage: 12~24Vdc (Selectable)
- Voltage tolerance: ±15%
- Current draw: 210mA at 12Vdc, 150mA at 24Vdc
- Operating temperature (C): -10 to +45
- LockÕs surface temperature: Current temperature ±20% (when power is on)
- Lock bolt sensor switch output (SPDT rated 3A at 125Vac)
- Humidity: 0~95% non-condensing
- 2000lbs jaw strength pull testing
- Tested to 1,000,000 cycles
Dimensions:
- 210 x 46 x 25 (hwd mm)
Write Your Own Review
| Brand | SRS |
|---|---|
| Strike Operation | Fail Locked (Fail secure) |
| Voltage | 24.0 Volt AC |
| Type of Device | Electric lock |
| Finish | Stainless steel |
