Videx Resistor Network for Button Expansion on 4333 Modules

Videx 125 Resistor Network for Button Expansion on 4333 Modules

Resistor network for button expansion of V-4333 module: Resistor network to increase the number of buttons possible with a V-4333 VX2300 speaker/camera module. The module is available with up to 2 call buttons. Using the V-125 with either the V-4843, V-4844 or V-4845 button module it is possible to increase this to 7 call buttons.

This module must be used in combination with speaker units V-4333 with firmware release 2.0 or higher. The module, in combination with standard 4000 series button expansion modules (V-4842, V- 4843, V-4844 and V-4845), allows to add up to 5 call buttons to the call buttons built-in the speaker unit to reach a maximum of 7 call buttons. To supply the LED of the button expansion modules make the connection as shown in figure 1 (see datasheet located under downloads). From V-4333 firmware version 2.3 or later, the switch n.6 sets the addressing order of the buttons so you can sort them as shown above.

Please Note: One V-125 is required for every 5 buttons on the panel.

Features:

• Videx Video 2 wire cabling

Technical Specifications:

• Housing/Mounting: 5 resistors module/fix to button expansion module
• Working Temperature: -10 +50C
